Energy Information at High Speed
Airflow
5796 Cubic Feet per Minute
Electricity Rate
51 Watts (excluded lights)
Airflow Efficiency
114 Cubic Feet Per Minute Per Watt
Downloads
Product Specification
Item #
604X
Dimensions
Height: 18.50"
Width: 37.00"
Length: "
Additional product details
Category
Fans
Subcategory
Ceiling Fans with Light
Finish
Gray
Style
Contemporary
Option
LED
Number of Blades
1 Blades
Category
Fan-Uni
Finish
Metro Gray
Family
Enigma
Voltage
240 V
Number of Bulbs
1 Bulbs
Additional Info
1 composite Metro Gray blade included
, 5796 CFM on High
, Compatible only with 220 volt electricity
, Limited Lifetime Warranty
, TR4-220 Transmitter Remote and Receiver unit with 9V battery included
Air Flow CFM
5796
Air Flow Efficiency
114
Amperage
0.43
Blade Finish
Metro Gray
Blade Pitch
18
Blade Span
60
Bulb Type
11 Watt Par30 LED
Canopy
5.75 Dia x 2.6 H
Diameter
9.5
Down Rod Included
6
Electricity Used
51
Harmonized Codes
8414.51.3000
Kelvin
3000
Length
38
Light Kit Included
Yes
Lumens / Light Output
760
Material
Composite
Motor Fan Speed
3
Motor RPM
164
Motor Size
188 X 18
Motor Type
AC
Remote Control Included
CR4WH-220
Ship Carton Height
11
Ship Carton Length
41
Ship Carton Width
16
Ship Weight
44
Sold By
Each
Warranty
Limited Lifetime
Weight
29
Wire Included
80"
Airflow Efficiency Low
157
Airflow Efficiency Medium
143
Blade Finish Method
Painted
Blade Material
Composite
Blade Reversible
No
Blade Sweep
60
Bulb Base
Par30
Bulb CRI
80
Bulb Wattage
75
Canopy Diameter
5.75 Dia
Canopy Height
2.6 H
Cap Included
No
Carton Cubic Feet
4.18
Cartons Per Unit
1
Case Height
11
Case Length
41
Case Quantity
1
Case Weight Pounds
44
Case Width
16
CEC Uploaded
No
Ceiling To Blade Edge
11.02
Ceiling To Bottom
17.53
CFM Low
1693
CFM Medium
3208
Compatible Accessories
DR1-12MG, DR1-18MG, DR1-24MG, DR1-36MG, DR1-48MG, DR1-60MG, DR1-72MG, SCB1-52
Compatible Controls
BTCR9-220
Compatible Wall Controls
C1-220, C3-220
Country of Origin
Taiwan
CRI
80
Current Draw High
0.43
Current Draw Low
0.26
Current Draw Medium
0.34
DOE-FTC Uploaded
No
DOEFTC Uploaded
No
Downrod Length
6
Exempt from DOE Procedure
Yes
Housing Diameter
9.5
Included Control
CR4WH-220
Included Control Type
Handheld
IP Rating
IP20
Leadwire
80
Max Watt
51
Motor Finish Method Type
Painted
Motor Reversible
No
Number of Blades
1
Number Of Speeds
3
Regulated Product
No
RPM High (VI)
164
RPM Low (II)
62
RPM Medium (IV)
99
Voltage Cycles
50 hz
Watts Low
11
Watts Medium
22
Watts Per Bulb
75
Other Details:
- 1 Composite Metro Gray Blade Included
- 5796 Cfm On High
- Compatible Only With 220 Volt Electricity
- Limited Lifetime Warranty
- Tr4-220 Transmitter Remote And Receiver Unit With 9v Battery Included
