Energy Information at High Speed
Airflow
1531 Cubic Feet per Minute
Electricity Rate
44.8 Watts (excluded lights)
Airflow Efficiency
34 Cubic Feet Per Minute Per Watt
Product Specification
Item #
K4TV
Dimensions
Height: 14.91"
Width: 23.70"
Length: "
Additional product details
Category
Fans
Subcategory
Ceiling Fans
Finish
Nickel
Style
Transitional
Option
Damp Rated
, LED
Voltage
10-99
Glass Finish or Style
Frosted
, Opal
Lumens
1601-2600
Number of Blades
4 Blades
Location Rating
Damp Rated
Wattage
20w
Category
Fan-Uni
Finish
Brushed Nickel
Option
Damp
Family
Gleam
Glass
Opal Frosted
Voltage
120 V
Number of Bulbs
1 Bulbs
Additional Info
1531 CFM on High
, 20 watt LED light kit and bulb included
, 3 speed AC motor with reverse switch, fan speed, light controls and sleep timer features
, Limited Lifetime Warranty
, TR500 handheld remote with 23A battery included
, WiFi or bluetooth compatible (required controls sold separately)
Air Flow CFM
1531
Air Flow Efficiency
34
Amperage
0.38
Blade Finish
Brushed Nickel
Blade Pitch
20
Bulb Type
20 Watt LED Module
Canopy
5.75 Dia x 2.57 H
Diameter
23.7
Down Rod Included
4.5
Electricity Used
44.8
Harmonized Codes
8414.51.3000
Kelvin
3000
Length
23.7
Light Kit Included
Yes
Lumens / Light Output
2200
Material
Composite
Motor Fan Speed
3
Motor RPM
563
Motor Size
82 X 30
Motor Type
AC
Remote Control Included
TR500
Ship Carton Height
11.5
Ship Carton Length
25.71
Ship Carton Width
25.63
Ship Weight
25.55
Sold By
Each
Warranty
Limited Lifetime
Weight
20.9
Airflow Efficiency Low
48
Airflow Efficiency Medium
39
Avg Airflow Efficiency
36
Avg CFM Energy
1206
Avg Energy Use Watts
33
Avg Estimated Yearly Energy Cost
9
Avg Estimated Yearly Energy Cost on HIGH
13
Blade Finish Method
Painted
Blade Material
Composite
Blade Reversible
No
Blade Sweep
16
Bulb Base
Connector Pin
Bulb CRI
90
Bulb Wattage
20
Canopy Diameter
5.75 Dia
Canopy Height
2.57 H
Cap Included
No
Carton Cubic Feet
4.39
Cartons Per Unit
1
Case Height
11.5
Case Length
25.71
Case Quantity
1
Case Weight Pounds
25.55
Case Width
25.63
CEC Uploaded
Yes
Ceiling To Blade Edge
14.67
Ceiling To Bottom
14.91
CFM Low
839
CFM Medium
1287
Compatible Accessories
CCK8002BN, DR1-12BN, DR1-18BN, DR1-24BN, DR1-36BN, DR1-48BN, DR1-60BN, DR1-72BN, DR1-CPBN, SCB1-52
Compatible Controls
BTCR9, BTR9, CRL4WH, WFR50
Compatible Wall Controls
CWRL4LA, CWRL4WH, WC2WH, WR501WH
Country of Origin
China
CRI
90
Current Draw High
0.38
Current Draw Low
0.25
Current Draw Medium
0.34
Damp Rated
Yes
DOE Classification
VSD
DOE-FTC Uploaded
Yes
DOEFTC Uploaded
Yes
Downrod Length
4.5
Exempt from DOE Procedure
No
Fan Energy Star
No
Housing Diameter
23.7
Included Control
TR500
Included Control Type
Handheld
Leadwire
54
Light Kit Energy Star
No
Max Ceiling Slope
27
Max Watt
44.8
Maximum Slope Degree
27
Motor Finish Method Type
Plated
Motor Reversible
Yes
Number of Blades
4
Number Of Speeds
3
Regulated Product
Yes
Reverse Switch Location
Motor Housing
RPM High (VI)
563
RPM Low (II)
325
RPM Low II
43
RPM Medium (IV)
461
Safety Rating
UL Approved, cUL Approved
Voltage Cycles
60 Hz
Watts Low
17.5
Watts Medium
33.3
Watts Per Bulb
20
Other Details:
- 1531 Cfm On High
- 20 Watt Led Light Kit And Bulb Included
- 3 Speed Ac Motor With Reverse Switch, Fan Speed, Light Controls And Sleep Timer Features
- Limited Lifetime Warranty
- Tr500 Handheld Remote With 23a Battery Included
- Wifi Or Bluetooth Compatible (required Controls Sold Separately)
