Energy Information at High Speed
Airflow
6379 Cubic Feet per Minute
Electricity Rate
52.21 Watts (excluded lights)
Airflow Efficiency
122 Cubic Feet Per Minute Per Watt
Product Specification
Item #
GD0P
Dimensions
Height: 14.54"
Width: 56.00"
Length: "
Additional product details
Category
Exterior
, Fans
Subcategory
Exterior Fans
, Outdoor Fans
Finish
Black
Style
Traditional
Option
Wet Rated
, LED
Voltage
10-99
Glass Finish or Style
Frosted
, Opal
Lumens
1101-1600
Number of Blades
3 Blades
Location Rating
Wet Rated
Wattage
18w
Category
Fan-Uni
Finish
Black
Option
Wet
Family
Xeno Wet
Glass
Opal Frosted
Voltage
120 V
Number of Bulbs
1 Bulbs
Additional Info
3 speed AC motor with reverse switch, light controls and sleep timer features
, 6605 CFM on High
, Limited Lifetime Motor Warranty
, Set of 3 composite 56 inch Wet Rated blades and 18 watt LED light kit with cover and bulb included
, TR500 handheld remote with 23A battery included
, WiFi or bluetooth compatible (required controls sold separately)
Air Flow CFM
6379
Air Flow Efficiency
122
Amperage
0.44
Blade Finish
Black
Blade Pitch
14
Bulb Type
18 Watt LED Module
Canopy
6.58 Dia x 2.62 H
Diameter
9.09
Down Rod Included
4.5
Electricity Used
52.21
Harmonized Codes
8414.51.3000
Kelvin
3000
Length
56
Light Kit Included
Yes
Lumens / Light Output
1400
Material
Composite
Motor Fan Speed
3
Motor RPM
161
Motor Size
188 x 25
Motor Type
AC
Remote Control Included
TR500
Ship Carton Height
13.66
Ship Carton Length
27.48
Ship Carton Width
13.62
Ship Weight
27.38
Sold By
Each
Warranty
Limited Lifetime
Weight
23.81
Airflow Efficiency Low
193
Airflow Efficiency Medium
155
Avg Airflow Efficiency
129
Avg CFM Energy
4280
Avg Energy Use Watts
33
Avg Estimated Yearly Energy Cost
9
Avg Estimated Yearly Energy Cost on HIGH
15
Blade Finish Method
Painted
Blade Material
Composite
Blade Reversible
No
Blade Sweep
56
Bulb Base
Connector Pin
Bulb CRI
90
Bulb Wattage
18
Canopy Diameter
6.58 Dia
Canopy Height
2.62 H
Cap Included
Yes
Carton Cubic Feet
2.96
Cartons Per Unit
1
Case Height
13.66
Case Length
27.48
Case Quantity
1
Case Weight Pounds
27.38
Case Width
13.62
CEC Uploaded
Yes
Ceiling To Blade Edge
10.24
Ceiling To Bottom
14.54
CFM Low
1901
CFM Medium
4130
Compatible Accessories
CCK8002BLW, DR1-CPBL, DR1SS-12BLW, DR1SS-18BLW, DR1SS-24BLW, DR1SS-36BLW, DR1SS-48BLW, DR1SS-60BLW, DR1SS-72BLW, SCB1-52
Compatible Controls
BTCR9, BTR9, CRL4WH, WFR50
Compatible Wall Controls
CWRL4LA, CWRL4WH, WC2WH, WR501WH
Country of Origin
China
CRI
90
Current Draw High
0.44
Current Draw Low
0.195
Current Draw Medium
0.32
DOE Classification
LSSD
DOE-FTC Uploaded
Yes
DOEFTC Uploaded
Yes
Downrod Length
4.5
Exempt from DOE Procedure
No
Fan Energy Star
No
Housing Diameter
9.09
Included Control
TR500
Included Control Type
Handheld
Leadwire
80
Light Kit Energy Star
No
Max Ceiling Slope
27
Max Watt
52.21
Maximum Slope Degree
27
Motor Finish Method Type
Painted
Motor Reversible
Yes
Number of Blades
3
Number Of Speeds
3
Regulated Product
Yes
Reverse Switch Location
Motor Housing
RPM High (VI)
161
RPM Low (II)
57
RPM Medium (IV)
110
Safety Rating
UL Approved, cUL Approved
Voltage Cycles
60 Hz
Watts Low
9.86
Watts Medium
26.62
Watts Per Bulb
18
Wet Rated
Yes
Other Details:
- 3 Speed Ac Motor With Reverse Switch, Light Controls And Sleep Timer Features
- 6605 Cfm On High
- Limited Lifetime Motor Warranty
- Set Of 3 Composite 56 Inch Wet Rated Blades And 18 Watt Led Light Kit With Cover And Bulb Included
- Tr500 Handheld Remote With 23a Battery Included
- Wifi Or Bluetooth Compatible (required Controls Sold Separately)
